(dimensions in inches)
Bearing Type - Cast iron housing
Dynamic Load Rating (Cr) - 2,887
Static Load Rating (Cor) - 1,499
Shaft Dia. (Fw) - 0.7500
Housing Width (b) - 2.3750
Mounting Hole Center-to-Center (e) - 3.5310
Housing Length (a) - 4.4380
Housing Base Thickness (g) - 0.4400
Bearing Inner Race Width (Bi) - 1.2210
Bearing Inner Race Width - Short Side (n) - 0.5000
Bearing Inner Race Width - Extended Side (m) - 0.7205
Mounting Bolt Size - 0.3130
Housing Number - FL204E
Mounting Hole Dia. (s) - 0.3906
Flange Assembly Height (Z) - 1.3130
Flange Height (l) - 1.0000
Mounting Base to Bearing Center (i) - 0.5938
Shaft Size (ds) - 3/4
Weight (g) - 480.18
Material - Cast iron housing, chrome steel bearing
Also available with eccentric locking collar.
Medium Duty, Heavy Duty and other available types are described in the Bearing Types information.
Various seal options and plated housing options are described in the Nomenclature and Bearing Types information.
