d - 80 mm

D - 146 mm

C - 12 mm

H - 35 mm

a - 5,7 mm

d1 - 5,6 mm

d2 - 10 mm

d3 - 4,6 mm

D1 - 130 mm

H1 - 23,35 mm

J - 92 mm

J1 - 138 mm

Weight - 2 Kg

Dynamic load rating radial (C) - 42,5 kN

Dynamic load rating axial (C) - 56 kN

Static load rating radial (C0) - 100 kN

Static load rating axial (C0) - 255 kN

Limiting speed - 530 r/min

• Model Number:RTC80
• Inner Diameter：80mm Outer Diameter：146mm Width：12mm
• Type：Complex Bearings
• Update date：2023-03-06
• Application:squeeze machine etc,Industrial,extruder,Logistics Equipment,air conditioning tools,Internal thread type,key lock,Pneumatic Actuator,Optical Instruments,ECG,atomizer class
• Similar models:INA ZARN3080-TV NTN ARN3080 INA YRT80-TV NTN AXN4580 INA ZARN4580-TV NBS ZARN90180LTN INA RTC80 INA ZARN90180-TV NBS ZARF3080LTN NBS ZARN3080TN
• BEARING POWER International Trading Co.,Ltd. specialize in RTC80 products，there is large inventory of INA RTC80 . We has been built up long-term cooperation with INA company, could make a bulk order of the RTC80 Which INA RTC80 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
