d - 55 mm

D - 100 mm

B - 25 mm

C - 25 mm

d2 - 65,9 mm

r1 min. - 1,5 mm

r2 min. - 1,5 mm

D1 - 88,5 mm

da min. - 64 mm

da max - 65,5 mm

Da max. - 91 mm

ra max. - 1,5 mm

Weight - 0,79 Kg

Basic dynamic load rating (C) - 27,6 kN

Basic static load rating (C0) - 10,6 kN

Fatigue load limit (Pu) - 0,54

Limiting speed - 4300 r/min

Calculation factor (e) - 0,19

Calculation factor (kr) - 0,045

Calculation factor (Y0) - 3,6

Calculation factor (Y1) - 3,3

Calculation factor (Y2) - 5,1

• Model Number:2211E-2RS1TN9
• Inner Diameter：55mm Outer Diameter：100mm Width：25mm
• Type：Self-Aligning Ball Bearings
• Update date：2025-12-09
• Application:medical equipment,Broadcasting System,electromagnet,Roller mill,Oral Equipment,Spectrum Products,Hydraulic Hose,Cylinder Micro,other processing,EEG,medical treatment
• Similar models:CX 2211 NKE 2211 ISB 2211TN9 ISB 2211-2RSKTN9+H311 SKF 2211EKTN9 SNR 2211 ISO 2211K ISB 2211-2RSTN9 NACHI 2211K NKE 2211-K
• BEARING POWER International Trading Co.,Ltd. specialize in 2211E-2RS1TN9 products，there is large inventory of SKF 2211E-2RS1TN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the 2211E-2RS1TN9 Which SKF 2211E-2RS1TN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
