d - 55 mm

D - 100 mm

B - 25 mm

C - 25 mm

d2 - 67,7 mm

r1 min. - 1,5 mm

r2 min. - 1,5 mm

D1 - 89,5 mm

da min. - 64 mm

Da max. - 91 mm

ra max. - 1,5 mm

Weight - 0,81 Kg

Basic dynamic load rating (C) - 39 kN

Basic static load rating (C0) - 13,4 kN

Fatigue load limit (Pu) - 0,7

Reference speed - 12000 r/min

Limiting speed - 8500 r/min

Calculation factor (e) - 0,23

Calculation factor (kr) - 0,045

Calculation factor (Y0) - 2,8

Calculation factor (Y1) - 2,7

Calculation factor (Y2) - 4,2

• Model Number:2211ETN9
• Inner Diameter：55mm Outer Diameter：100mm Width：25mm
• Type：Self-Aligning Ball Bearings
• Update date：2023-03-10
• Application:food safety,electronic components,Hydraulic Couplings,Display Devices,hydraulic pump,Insect Capture,Hydraulic Press,chamfering machine etc,turret industry,intermediate,Gripper Swing
• Similar models:SNR 2211KEEG15 CRAFT 2211 FAG 2211-K-2RS-TVH-C3+H311 AST 2211 CX 2211-2RS ISO 2211K-2RS+H311 FBJ 2211 CX 2211 FAG 2211-K-TVH-C3 ISB 2211-2RSKTN9
• BEARING POWER International Trading Co.,Ltd. specialize in 2211ETN9 products，there is large inventory of SKF 2211ETN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the 2211ETN9 Which SKF 2211ETN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
