d - 30 mm

D - 72 mm

B - 19 mm

C - 19 mm

b - 1,9 mm

d1 - 44,6 mm

f - 1,7 mm

r0 max. - 0,6 mm

r1 min. - 1,1 mm

r2 min. - 1,1 mm

C - 3,28 mm

D2 - 61,9 mm

D3 - 68,81 mm

D4 - 78,6 mm

ba min. - 2,2 mm

Ca max. - 4,98 mm

da min. - 37 mm

da max - 44,5 mm

Da max. - 65 mm

Db min. - 80 mm

ra max. - 1 mm

Weight - 0,37 Kg

Basic dynamic load rating (C) - 29,7 kN

Basic static load rating (C0) - 21,6 kN

Fatigue load limit (Pu) - 0,93

Reference speed - 18000 r/min

Limiting speed - 11000 r/min

Calculation factor (kr) - 0,05

• Model Number:306-2ZNR
• Inner Diameter：30mm Outer Diameter：72mm Width：19mm
• Type：Deep Groove Ball Bearings
• Update date：2023-03-04
• Application:Flame Cutting,transportation equipment,medical equipment,axle lathe,equipment,Hairbrush device,engineering machinery,Vertical pull,Medium and large motor,hydraulic pump,injection molding machine
• Similar models:NTN 6306BXLLU/32C4 NACHI 6306ZE SKF W6306-2RS1 NKE 6306-NR NKE 6306-2Z PFI 6306-2RSd32C3 FAG 62306-2RSR ZEN 62306-2RS SKF BB1-3065C ZEN S6306
• BEARING POWER International Trading Co.,Ltd. specialize in 306-2ZNR products，there is large inventory of SKF 306-2ZNR . We has been built up long-term cooperation with SKF company, could make a bulk order of the 306-2ZNR Which SKF 306-2ZNR is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
