d - 220 mm

D - 400 mm

B - 65 mm

C - 65 mm

a - 164 mm

d1 - 291 mm

d2 - 259 mm

r1 min. - 4 mm

r2 min. - 4 mm

r3 min. - 1,5 mm

r4 min. - 1,5 mm

D1 - 334 mm

da min. - 237 mm

Da max. - 383 mm

ra max. - 3 mm

rb max. - 1,5 mm

Db max - 391 mm

Weight - 37 Kg

Basic dynamic load rating (C) - 390 kN

Basic static load rating (C0) - 560 kN

Fatigue load limit (Pu) - 13,4

Reference speed - 1800 r/min

Limiting speed - 1800 r/min

• Model Number:7244BCBM
• Inner Diameter：220mm Outer Diameter：400mm Width：65mm
• Type：Angular Contact Ball Bearings
• Update date：2023-03-10
• Application:ultra-quiet generators,special broaching machine,Energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving energy saving,set bacteria instrument,Air,engineering machine,surgical instruments,clean stationery,ventilation heating equipment,other lathe,wheel lathe
• Similar models:FAG B7244-E-T-P4S NTN 7244 ISO 7244C CX 7244ATBP4 NKE 7244-BCB-MP KOYO 7244 NSK 7244B NTN 7244B AST 7244C NKE 7244-B-MP
• BEARING POWER International Trading Co.,Ltd. specialize in 7244BCBM products，there is large inventory of SKF 7244BCBM . We has been built up long-term cooperation with SKF company, could make a bulk order of the 7244BCBM Which SKF 7244BCBM is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
