d₁ - 500 mm

D - 780 mm

B₁ - 265 mm

d₂ - - 601 mm

d₃ - 630 mm

D₁ - - 705 mm

B - 185 mm

B₂ - 68 mm

B₅ - 90 mm

s₁ - 35.7 mm

r_1,2 - min. - 6 mm

d_a - max. - 638 mm

d_b - min. - 551 mm

D_a - min. - 681 mm

D_a - max. - 757 mm

B_a - min. - 20 mm

C_a - min. - 2.5 mm

r_a - max. - 5 mm

Basic dynamic load rating - C - 5100 kN

Basic static load rating - C₀ - 9500 kN

Fatigue load limit - P_u - 630 kN

Reference speed - 600 r/min

Limiting speed - 800 r/min

Factor - k₁ - 0.12

Factor - k₂ - 0.101

Mass bearing and adapter sleeve - 390 kg

• Model Number:C 30/530 KM + OH 30/530 H
• Inner Diameter：780mm Outer Diameter：500mm Width：265mm
• Type：Cylindrical Roller Bearings
• Update date：2023-03-04
• Application:garden machinery,security equipment,sheet industry,leather processing,medical equipment,plastic molding,marine test,Grinding and polishing equipment,Body shaping,Switch,car
• Similar models:NACHI 24068EK30 NACHI 23130EX1 FBJ NJ2309 SKF C3052 CYSD NN3026/W33 NTN NN4930KC1NAP4 FAG NJ309VH.NR.C4 NACHI 231/530EK NKE NNCL49/530-V NTN NN30/950KWD1C1NAP5
• BEARING POWER International Trading Co.,Ltd. specialize in C30/530KM+OH30/530H products，there is large inventory of SKF C 30/530 KM + OH 30/530 H . We has been built up long-term cooperation with SKF company, could make a bulk order of the C 30/530 KM + OH 30/530 H Which SKF C30/530KM+OH30/530H is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
