d - 190 mm

D - 320 mm

B - 128 mm

d₂ - - 222 mm

D₁ - - 284 mm

s₁ - 20 mm

s₂ - 10.1 mm

r_1,2 - min. - 3 mm

d_a - min. - 204 mm

d_a - max. - 233 mm

D_a - max. - 306 mm

r_a - max. - 2.5 mm

Basic dynamic load rating - C - 1630 kN

Basic static load rating - C₀ - 2464 kN

Fatigue load limit - P_u - 244 kN

Limiting speed - 130 r/min

Factor - k₁ - 0.104

Factor - k₂ - 0.103

Mass bearing - 43 kg

• Model Number:C 4138 K30V
• Inner Diameter：320mm Outer Diameter：190mm Width：128mm
• Type：Cylindrical Roller Bearings
• Update date：2025-12-12
• Application:other rubber,light therapy instrument,scientific instruments,motor,hydraulic cylinder buffer,chromatography,pipe fittings Steel industry,Oral Equipment,knitted fabrics,Ball screw,molding machine
• Similar models:NACHI 24138E SKF C4138K30V SKF C4138-2CS5V/GEM9 ISB NNU4138K30M/W33 ISB NNU4138M/W33 SKF C4138V FAG NNU4138-M NACHI 24138EK30
