d - 25 mm
H - 120 mm
A - 82 mm
A1 - 78.74 mm
A2 - 32 mm
A3 - 15 mm
d1 - 34 mm
D1 - 88 mm
D2 - 80 mm
D3 - 40 mm
Basic dynamic load rating - C - 36.5 kN
Basic static load rating - C0 - 104 kN
Fatigue load limit - Pu - 3.9 kN
Limiting speed, Preload class A - 4500 r/min
Limiting speed for oil lubrication - 2250 mm/min
Preload class A - 3160 N
Preload class B - 6320 N
Frictional moment, Preload class A - 0.138 N·m
Frictional moment, Preload class B - 0.24 N·m
Static Axial rigidity, Preload class A - 1450 N/micron
Static Axial rigidity, Preload class B - 1850 N/micron
Weight - 3.5 kg
