d - 44.45 mm

A - 39 mm

A₁ - 14 mm

A₃ - H14 - 3.2 mm

A₅ - 23 mm

B - 49.2 mm

D_a - H11 - 119.1 mm

D_b1 - 102 mm

D_b2 - 112 mm

J - 105 mm

L - 137 mm

H - 16 mm

s₁ - 30.2 mm

T - 54.2 mm

J₆ - 123 mm

J₇ - 33.5 mm

N₄ - 4 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 24.5 mm

Basic dynamic load rating - C - 33.2 kN

Basic static load rating - C₀ - 21.6 kN

Fatigue load limit - P_u - 0.915 kN

Limiting speed - 4300 r/min

Mass bearing unit - 1.9 kg

Thread - G₂ - 5/16-24 UNF

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m

• Model Number:FY 1.3/4 TF
• Inner Diameter：44,45mm Outer Diameter：39mm Width：14mm
• Type：Bearing Units
• Update date：2023-03-03
• Application:sewage pump,rock drilling machinery,medical treatment,non-ferrous metal alloy,small diesel generators,noise inspection,power protection,sanitation facilities,Broadcasting System,transportation equipment,turret industry
• Similar models:SNR UKP205H KOYO UCFCX15 NKE PCJY50-N SNR UKT213H+WB FYH SBPTH202-90 CX UCF309 SKF SYF50TF INA GLCTE20 INA KSR16-L0-12-10-15-09 SNR EXP315
• BEARING POWER International Trading Co.,Ltd. specialize in FY1.3/4TF products，there is large inventory of SKF FY 1.3/4 TF . We has been built up long-term cooperation with SKF company, could make a bulk order of the FY 1.3/4 TF Which SKF FY1.3/4TF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
