d - 40 mm

A - 38.5 mm

A₁ - 14 mm

A₃ - H14 - 3.2 mm

A₅ - 23.5 mm

B₁ - 56.3 mm

D_a - H11 - 115.9 mm

D_b1 - 98 mm

D_b2 - 106 mm

J - 101.5 mm

L - 130 mm

H - 14 mm

s₁ - 34.9 mm

T - 58.9 mm

J₆ - 118 mm

J₇ - 34 mm

N₄ - 4 mm

R_G - 1/4-28 UNF

R₁ - 25.5 mm

Basic dynamic load rating - C - 30.7 kN

Basic static load rating - C₀ - 19 kN

Fatigue load limit - P_u - 0.8 kN

Limiting speed - 950 r/min

Mass bearing unit - 1.9 kg

Thread - G₂ - M10x1

Hexagonal key size for grub screw - H - 5 mm

Recommended tightening torque for grub screw - 16.5 N·m

• Model Number:FY 40 WDW
• Inner Diameter：40mm Outer Diameter：38,5mm Width：14mm
• Type：Bearing Units
• Update date：2025-12-11
• Application:pneumatic,Pneumatic Control Elements,hydraulic actuator,turret industry,electromagnetic clutch,ventilator anesthesia machine etc,Forming mold,ignition system,power source,product accessories,knitted fabrics
• Similar models:SKF FYJ40TF INA KGBS40-PP-AS SKF TU40TF FYH UCFL213-40E SKF SYF40TF NKE RAT40 INA PMEY40-N KOYO UCFC213-40 SKF P40RM SKF FY40FM
• BEARING POWER International Trading Co.,Ltd. specialize in FY40WDW products，there is large inventory of SKF FY 40 WDW . We has been built up long-term cooperation with SKF company, could make a bulk order of the FY 40 WDW Which SKF FY40WDW is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
