d - 25 mm

A - 27 mm

A₁ - 7 mm

A₃ - 6 mm

B - 34.1 mm

B₄ - 5 mm

D_a - h8 - 70 mm

D_b - 70 mm

J - 90 mm

J₁ - 63.6 mm

L - 115 mm

H - 12 mm

s₁ - 19.8 mm

T - 29.8 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 16 mm

Basic dynamic load rating - C - 14 kN

Basic static load rating - C₀ - 7.8 kN

Fatigue load limit - P_u - 0.335 kN

Limiting speed with shaft tolerance h6 - 7000 r/min

Weight - 0.92 kg

Thread - G₂ - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

• Model Number:FYC 25 TF
• Inner Diameter：25mm Outer Diameter：27mm Width：7mm
• Type：Bearing Units
• Update date：2025-12-15
• Application:hydraulic actuator,Perfusion device,Doppler,gas turbine,medical equipment,hydraulic connector,Hydraulic Press,packing equipment,chuck industry,packaging machinery,Low-voltage electrical equipment
• Similar models:INA PCJT50-N-FA125 INA PCSLT25 NKE PCJY25-N NKE RATY25 INA PCJY25-N SKF P62R-25RM FYH UCTH208-25-300 INA PCJT60-N-FA125 FYH UCT208-25 SKF FYK25LEF
• BEARING POWER International Trading Co.,Ltd. specialize in FYC25TF products，there is large inventory of SKF FYC 25 TF . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYC 25 TF Which SKF FYC25TF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
