d_a - 100 mm

A₁ - 98 mm

A₂ - 30 mm

T - max. - 98.9 mm

B - 86 mm

H - 270 mm

H₁ - 135 mm

J - 219 mm

L - 270 mm

D_a - 220 mm

H - 23 mm

a - 6 mm

S - 2.5 mm

J₅ - 122 mm

J₆ - 78 mm

N₄ - max. - 8 mm

Basic dynamic load rating - C - 425 kN

Basic static load rating - C₀ - 490 kN

Fatigue load limit - P_u - 49 kN

Limiting speed - 2000 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 140 mm

Basic Designation bearing - 22220 E

P_a - 35 kN

P₁ - 190 kN

P₂ - 200 kN

P₃ - 640 kN

Mass bearing unit - 23 kg

Diameter - G - 20 mm

• Model Number:FYNT 100 L
• Inner Diameter：100mm Outer Diameter：98mm Width：30mm
• Type：Bearing Units
• Update date：2025-12-15
• Application:magnetic elements,top industry,Cylinder Micro,outdoor equipment,tapping machine,Spectrum Products,Food testing,fruit and vegetable processing,gear grinding machine,oral medical device,blood cell reagent
• Similar models:INA RTUE100 SNR ESFD204M100 KOYO UCTL204-100 KOYO SBNPTH201-100 NKE RCJO100 SKF FYNT100L KOYO UCTL206-100 SNR ESFD208M100 FYH SBNPTH205-100 SNR ESFD203M100
• BEARING POWER International Trading Co.,Ltd. specialize in FYNT100L products，there is large inventory of SKF FYNT 100 L . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYNT 100 L Which SKF FYNT100L is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
