d - 50 mm

A - 43 mm

A₁ - 15 mm

A₃ - H14 - 3.2 mm

A₅ - 29.5 mm

B - 51.6 mm

B₄ - 9 mm

D_a - H11 - 101.6 mm

D_b1 - 107 mm

D_b2 - 116 mm

J - 157 mm

H - 189 mm

L - 116 mm

H - 18 mm

s₁ - 32.6 mm

T - 60.6 mm

J₆ - 127 mm

J₇ - 20 mm

N₄ - 2 mm

R_G - 1/4-28 UNF

R₁ - 28.5 mm

R_α - 45 °

Basic dynamic load rating - C - 35.1 kN

Basic static load rating - C₀ - 23.2 kN

Fatigue load limit - P_u - 0.98 kN

Limiting speed - 800 r/min

Mass bearing unit - 2.05 kg

Thread - G₂ - M10x1

Hexagonal key size for grub screw - H - 5 mm

Recommended tightening torque for grub screw - 16.5 N·m

• Model Number:FYTB 50 TDW
• Inner Diameter：50mm Outer Diameter：43mm Width：15mm
• Type：Bearing Units
• Update date：2025-12-24
• Application:Pump,Laser Devices,powder metallurgy,wheel lathe,diving equipment,other lathe,noise inspection,quality inspection equipment,milling head plug,Broadcasting System,Machine Tool Accessories
• Similar models:INA PCF50 SKF FYT50TF/VA201 INA PHE50 SKF SYNT50LTF INA PTUEY50 NKE RCJO50 KOYO UCTU212-500 NKE PME50-N SKF SYJ50KF+HE2310 SKF FYJ50KF+H2310
• BEARING POWER International Trading Co.,Ltd. specialize in FYTB50TDW products，there is large inventory of SKF FYTB 50 TDW . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYTB 50 TDW Which SKF FYTB50TDW is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
