d - 25 mm

A - 29.4 mm

A₁ - 13.5 mm

A₅ - 24.9 mm

B - 34.1 mm

B₄ - 5 mm

D_b1 - 65.1 mm

D_b2 - 69.9 mm

J - 98.8 mm

H - 123.8 mm

L - 69.9 mm

H - 12.7 mm

s₁ - 19.8 mm

T - 36.5 mm

R_G - 1/4-28 UNF

R₁ - 18.2 mm

R_α - 45 °

Basic dynamic load rating - C - 11.9 kN

Basic static load rating - C₀ - 7.8 kN

Fatigue load limit - P_u - 0.335 kN

Limiting speed - 4300 r/min

Mass bearing unit - 0.71 kg

Thread - G₂ - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

• Model Number:FYTWR 25 YTHR
• Inner Diameter：25mm Outer Diameter：29,4mm Width：13,5mm
• Type：Bearing Units
• Update date：2023-03-07
• Application:Rolling mill gear box,electromagnet,dynamic blood pressure,Optical Instruments,aerial work platform,lifting chain,bathroom facilities,Display Devices,Industrial Electromechanical,Warehouse Shelf Equipment,spring industry
• Similar models:INA RCJTZ25 AST UCFL208-25 INA KGHA25-PP SKF PF25WF FYH UCP208-25 INA PCJ25-N-FA125 INA RATR25 SKF FYTB25WF INA RASE20-N-FA125 SKF SYJ25KF+SYJ505
• BEARING POWER International Trading Co.,Ltd. specialize in FYTWR25YTHR products，there is large inventory of SKF FYTWR 25 YTHR . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYTWR 25 YTHR Which SKF FYTWR25YTHR is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
