d - 12 mm

D - 32 mm

B - 10 mm

C - 12,6 mm

d1 - 18,4 mm

r1 min. - 0,6 mm

r2 min. - 0,6 mm

D1 - – mm

D2 - 27,34 mm

da min. - 16,2 mm

da max - 18,4 mm

Da max. - 27,8 mm

db max. - 18 mm

db min - 16,2 mm

ra max. - 0,6 mm

Weight - 0,041 Kg

Basic dynamic load rating (C) - 7,28 kN

Basic static load rating (C0) - 3,1 kN

Fatigue load limit (Pu) - 0,132

Limiting speed - 14000 r/min

Calculation factor (f0) - 12

Calculation factor (kr) - 0,025

• Model Number:ICOS-D1B01 TN9
• Inner Diameter：12mm Outer Diameter：32mm Width：10mm
• Type：Deep Groove Ball Bearings
• Update date：2023-03-15
• Application:light therapy instrument,other accessories,granulator,,Special Equipment,Industrial Electromechanical,machining,Industrial Adhesive,garbage disposal,special broaching machine,meat products machine
• Similar models:SNR AB44061S01 KOYO 6301 NSK 6010N NSK 6010 SKF 6305/VA201 Timken YA014RR KOYO MLF8012 NTN 6201LLBD2 Timken 90BIC401 INA GAY012-NPP-B-AS2/V
• BEARING POWER International Trading Co.,Ltd. specialize in ICOS-D1B01TN9 products，there is large inventory of SKF ICOS-D1B01 TN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the ICOS-D1B01 TN9 Which SKF ICOS-D1B01TN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  22311 W33	55	120	43	MPZ	Spherical Roller Bearings
  23322 MBW33	110	240	92,1	MPZ	Spherical Roller Bearings
  51132 M	160	200	31	ISB	Thrust Ball Bearings
  6008ZZ	40	68	15	NTN	Deep Groove Ball Bearings
  6215DDU	75	130	25	NSK	Deep Groove Ball Bearings
  6314-2RS	70	150	35	CYSD	Deep Groove Ball Bearings
  BT4B 334125/HA1	761,873	555,233	692,15	SKF	Tapered Roller Bearings
  EE755285/755360	723,9	914,4	84,138	NSK	Cylindrical Roller Bearings
  K35x42x16	35	42	16	CX	Needle Roller Bearings
  RP455129A	45	51	28,9	KOYO	Needle Roller Bearings
  LM961548/11	342,9	457,098	68,262	ISO	Tapered Roller Bearings
  LUCS 60		60		SKF	Linear Bearings
  NNU 4992 SPW33	460	620	160	ISB	Cylindrical Roller Bearings
  W2-1/8	53,975	81,76	22,225	INA	Thrust Ball Bearings
  X33117/Y33117	85	140	41	Timken	Tapered Roller Bearings
  RT-617				INA	THRUST ROLLER BEARINGS
  6013.2RSR	65	100	18	FAG	DEEP GROOVE BALL BEARINGS
  BU1213L	65	120	23	Hyatt	CYLINDRICAL ROLLER BEARINGS
  CR-7/8-XBE			.5000	Smith	NEEDLE BEARINGS
  LS160200	160	200		Torrington	THRUST NEEDLE BEARINGS
