D - 72 mm

d - 24 mm

B - 80 mm

C - 28 mm

B₁ - 49.5 mm

B₂ - 11 mm

C₁ - 1.3 mm

d₁ - 44 mm

G - M 24x1.5

G₁ - 25 mm

M - 8 mm

M₁ - 4 mm

SW - 14 mm

r_1,2 - min. - 1.1 mm

Basic dynamic load rating - C - 39.6 kN

Basic static load rating - C₀ - 45 kN

Fatigue load limit - P_u - 5.6 kN

Maximum dynamic radial loads - F_r - 47.5 kN

Maximum static radial loads - F_0r - 68 kN

Limiting speed - 2600 r/min

Mass support roller - 1.02 kg

Recommended tighthening torque - 220 N·m

Grease fitting - NIP A3x9.5

Hexagonal nut - M 24x1.5

Lubrication adapter - AP 14

• Model Number:PWKR 72.2RS
• Inner Diameter：24mm Outer Diameter：72mm Width：80mm
• Type：Cylindrical Roller Bearings
• Update date：2023-03-10
• Application:fruit and vegetable processing,Oral Equipment,mobile toilet,aerial work equipment,cooling system,industrial equipment,sheet industry,Spectral Products,screen filter,agriculture,sanitation facilities
• Similar models:NSK 74472/74850 SKF NNU4972B/SPW33 NTN RNU7203 CX NJ1072 NSK LM772748/LM772710 NTN R0725V NTN 4R7205 ISO HK172514 NTN NN3972KC1NAP4 ISO BK172514
• BEARING POWER International Trading Co.,Ltd. specialize in PWKR72.2RS products，there is large inventory of SKF PWKR 72.2RS . We has been built up long-term cooperation with SKF company, could make a bulk order of the PWKR 72.2RS Which SKF PWKR72.2RS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
