Fw - 25 mm

D - 35 mm

C - 17 mm

r1 min. - 0,3 mm

r2 min. - 0,3 mm

E - 29 mm

Da - 29,5 mm

ra max. - 0,3 mm

da - 28,4 mm

Db - 25,6 mm

Weight - 0,053 Kg

Basic dynamic load rating (C) - 14,2 kN

Basic static load rating (C0) - 26,5 kN

Fatigue load limit (Pu) - 3,1

Reference speed - 16000 r/min

Limiting speed - 18000 r/min

• Model Number:RNAO25x35x17
• Inner Diameter：25mm Outer Diameter：35mm Width：17mm
• Type：Needle Roller Bearings
• Update date：2025-12-24
• Application:roller lathe,Machine tools,chamfering machine etc,relay,power tools,multi-knife lathe,horizontal processing,Spectrum Products,ventilation equipment,preservation equipment,Special Equipment
• Similar models:NSK RLM2512 NSK RLM3025 IKO TLAM5525 NBS NKI75/25 NTN NK73/25R NSK FWF-212513 IKO KT606825 FBJ K40X48X25 NTN NK12X19X25 KOYO 25V3724
• BEARING POWER International Trading Co.,Ltd. specialize in RNAO25x35x17 products，there is large inventory of SKF RNAO25x35x17 . We has been built up long-term cooperation with SKF company, could make a bulk order of the RNAO25x35x17 Which SKF RNAO25x35x17 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
