d - 10 mm

d2 max. - 29 mm

d3 - 15 mm

d4 max. - 20 mm

dk - 19 mm

h1 - 43 mm

l3 min. - 20 mm

l4 max. - 58 mm

l5 - 6,5 mm

l7 min. - 14 mm

r1 min. - 0,3 mm

B - 14 mm

C1 max - 10,5 mm

w - 17 Tolerance h14

Thread (G) - M10x1,25 Tolerance 6H

Angle - 13 °

Weight - 0,079 Kg

Basic dynamic load rating (C) - 9,8 kN

Basic static load rating (C0) - 14,3 kN

• Model Number:SIKB10F/VZ019
• Inner Diameter：10mm Outer Diameter：mm Width：mm
• Type：Plain Bearings
• Update date：2025-12-12
• Application:mobile toilet,Cylinder Special,Insect Capture,orthodontic material,printing equipment,vacuum suction cup,metal mold,tower crane,Animal Tracking,office equipment,engineering machine
• Similar models:LS GX100S AST AST650110130120 AST AST800150100 AST AST80095100 INA EGB140100-E40 AST GE10N LS GX10T SKF PCMF101212E AST AST800105100 INA GIPFL10PW
• BEARING POWER International Trading Co.,Ltd. specialize in SIKB10F/VZ019 products，there is large inventory of SKF SIKB10F/VZ019 . We has been built up long-term cooperation with SKF company, could make a bulk order of the SIKB10F/VZ019 Which SKF SIKB10F/VZ019 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
