d - 35 mm

A - 45 mm

A₁ - 27 mm

A₅ - 22 mm

B - 42.9 mm

H - 93.5 mm

H₁ - 47.6 mm

H₂ - 19 mm

J - 126 mm

J - max. - 133 mm

J - min. - 119 mm

L - 164 mm

H - 21.5 mm

N₁ - 14.5 mm

s₁ - 25.4 mm

Basic dynamic load rating - C - 25.5 kN

Basic static load rating - C₀ - 15.3 kN

Fatigue load limit - P_u - 0.655 kN

Limiting speed - 5300 r/min

Weight - 0.65 kg

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

• Model Number:SYK 35 TF
• Inner Diameter：35mm Outer Diameter：45mm Width：27mm
• Type：Bearing Units
• Update date：2025-12-11
• Application:security equipment,Material handling equipment,Low-voltage electrical equipment,,Animal Tracking,rolling mill roll neck and slowdown device,food / grain / food equipment,machine lathe,hydraulic control element,gear grinding machine,Equipment
• Similar models:INA TSHE35-N NKE FLCTEY35 INA TASE35-N NKE PCJT35-N SKF FY35FM KOYO UCFL211-35 NKE PMEY35-N INA RATY35 SKF P35TF SKF FY35TF/VA228
• BEARING POWER International Trading Co.,Ltd. specialize in SYK35TF products，there is large inventory of SKF SYK 35 TF . We has been built up long-term cooperation with SKF company, could make a bulk order of the SYK 35 TF Which SKF SYK35TF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
