d_a - 45 mm

A - 60 mm

B - 65 mm

H - 118 mm

H₁ - 60 mm

H₂ - 25 mm

J - 170 mm

L - 205 mm

H - 20 mm

N₁ - 15 mm

S - 2.5 mm

J₆ - 185 mm

J₇ - 21 mm

N₄ - max. - 6 mm

A₃ - 52 mm

A₅ - 23 mm

b_a - min. - 34 mm

b_a - max. - 43 mm

Basic dynamic load rating - C - 102 kN

Basic static load rating - C₀ - 98 kN

Fatigue load limit - P_u - 10.8 kN

Limiting speed - 3500 r/min

Calculation factor - e - 0.26

Calculation factor - Y₁ - 2.6

Calculation factor - Y₂ - 3.9

Diameter - d_m - 65 mm

Basic Designation bearing - 22209 E

P_a - 15 kN

P_0° - 170 kN

P_55° - 280 kN

P_90° - 170 kN

P_120° - 110 kN

P_150° - 100 kN

P_180° - 115 kN

Mass bearing unit - 4 kg

Diameter - G - 12 mm

• Model Number:SYNT 45 L
• Inner Diameter：45mm Outer Diameter：60mm Width：65mm
• Type：Bearing Units
• Update date：2023-03-09
• Application:Spectral Products,Rolling mill,ultra-quiet generators,Industrial,Special Equipment,wall materials,Switch,chemical raw materials and reagents,other lathe,instrumentation instrument,Other Measurements
• Similar models:INA PCJY45 NKE RCJT45 NKE PME45 INA PCJTY45 SKF SYJ45TF SKF TU45FM SKF SY45PF SKF P45RM SKF FYTJ45KF+H2309 NKE RTUEY45
• BEARING POWER International Trading Co.,Ltd. specialize in SYNT45L products，there is large inventory of SKF SYNT 45 L . We has been built up long-term cooperation with SKF company, could make a bulk order of the SYNT 45 L Which SKF SYNT45L is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
