d_a - 50 mm

A - 70 mm

B - 65 mm

H - 131 mm

H₁ - 70 mm

H₂ - 28 mm

J - 210 mm

L - 255 mm

H - 24 mm

N₁ - 18 mm

S - 2.5 mm

J₆ - 234 mm

J₇ - 26 mm

N₄ - max. - 8 mm

A₃ - 62 mm

A₅ - 29.5 mm

b_a - min. - 34 mm

b_a - max. - 55 mm

Basic dynamic load rating - C - 104 kN

Basic static load rating - C₀ - 108 kN

Fatigue load limit - P_u - 11.8 kN

Limiting speed - 1650 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 70 mm

Basic Designation bearing - 22210 E

P_a - 15 kN

P_0° - 190 kN

P_55° - 330 kN

P_90° - 200 kN

P_120° - 130 kN

P_150° - 115 kN

P_180° - 140 kN

Mass bearing unit - 5.8 kg

Diameter - G - 16 mm

• Model Number:SYNT 50 LTF
• Inner Diameter：50mm Outer Diameter：70mm Width：65mm
• Type：Bearing Units
• Update date：2023-03-14
• Application:chromatography,pneumatic Pump,medical equipment,Forging machine,vacuum filter,rock drilling machinery,other lathe,Spectrum Products,Power equipment,Optical Instruments,electromagnetic clutch
• Similar models:KOYO UCTH205-15-150 FYH UCTH206-150 INA GRA50 KOYO UCFL216-50E FYH UCTH206-19-150 KOYO UCTU209-500 SKF FYWK50LTHR FYH UCTU318-500 FYH UCTU209-500 SKF SYJ50KF+HE2310
• BEARING POWER International Trading Co.,Ltd. specialize in SYNT50LTF products，there is large inventory of SKF SYNT 50 LTF . We has been built up long-term cooperation with SKF company, could make a bulk order of the SYNT 50 LTF Which SKF SYNT50LTF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
